Manufacturer-source research · Laptop Accessories

USB-C docks: compare display limits, Ethernet and shared charging

Compare Anker 565 A8388 and CalDigit SOHO by exact ports, Mac versus Windows displays and concurrent laptop power. No current price ceiling claimed.

By Published Updated

By Daily Carry Lab. Primary documentation checked October 14, 2026 (Pacific).

Affiliate disclosure: As an Amazon Associate, Daily Carry Lab earns from qualifying purchases. Retailer links may earn a commission at no extra cost to you.

Research disclosure: We have not tested these products. Selection uses primary documentation and the compatibility decisions below; no DCL ratings or measured performance are claimed.

Choose a USB-C dock by display arrangement, host video support and actual laptop charging, then by the ports you need. The connector alone does not establish any of those capabilities. This guide retains its historical URL, but makes no current under-$100 promise.

We selected Anker 565 USB-C Hub, A8388, and CalDigit USB-C SOHO Dock for documented HDMI/DisplayPort expansion with different card-reader, Ethernet and charging tradeoffs. SOHO remains from the previous revision; A8388 replaces the single-HDMI Plugable example to make the two-output comparison more useful. We have not tested charging, heat, monitor compatibility or transfer performance.

Exact ports and display limits

ModelUseful port selectionSingle displayTwo external displays
Anker 565 A8388HDMI + DisplayPort; one 10Gbps USB-C and one 10Gbps USB-A; two 480Mbps USB-A; Gigabit Ethernet; SD/microSD UHS-I; 3.5mm audioUp to 4K60 with a DP 1.4 host; 4K30 with DP 1.2Windows: up to 2K60 with DP 1.4 or 1080p60 with DP 1.2; macOS external screens show identical content
CalDigit SOHOHDMI 2.0b + DisplayPort 1.4; one 10Gbps USB-C and one 10Gbps USB-A; SD/microSD UHS-IIUp to 4K60 with DP 1.4Dual mirrored 4K60 on Mac/Windows; dual extended 4K30 on Windows, subject to DP 1.4 host/GPU

Sources: Anker’s exact A8388 specifications, Anker’s resolution conditions and CalDigit SOHO documentation. The 565’s official display diagram shows the same image on both macOS external screens; two connectors do not mean two independent Mac desktops.

These are upper specification limits. Check the laptop’s exact port, GPU, operating system, monitor input and cable. A dock cannot add an unsupported host display path, and a Thunderbolt-capable computer does not make either selected device a Thunderbolt-transport dock. If you require two independent Mac external screens, neither documented dual-output arrangement establishes that requirement.

Anker 565: Ethernet, audio and more USB-A sockets

A8388 is the more relevant candidate when wired Ethernet, a 3.5mm connection or extra USB-A sockets matter. Two of its three USB-A ports are 480Mbps, rather than 10Gbps; put storage and other peripherals in the appropriate port. Its USB-C data port is not a video output, and its separate PD-input port is for charging rather than a second data connection.

Drawbacks: macOS dual outputs repeat the same external image. Windows dual-display limits are lower than the single-display headline, and host DP version matters. Anker excludes Switch and SuperDrive in the reviewed regional notes. We make no universal host-compatibility claim.

SOHO: UHS-II cards and a detachable host cable

SOHO is worth comparing when its UHS-II SD/microSD readers, compact port selection and detachable host cable fit the task. Its USB bandwidth is shared; two individually listed 10Gbps data ports do not establish 20Gbps of simultaneous host throughput. Ethernet or 3.5mm audio is not among the listed SOHO interfaces, so count any additional adapters in the workspace plan.

Drawbacks: the documented Windows extended mode is dual 4K30, not dual 4K60. macOS dual output is mirrored. The supplied 0.5m USB-C cable is documented, but an optional longer cable must still support the required data/video path; charging wattage alone does not establish that.

Input watts versus concurrent laptop power

Both products use a separate PD-input connection. Anker lists 100W input and up to 85W to the laptop for A8388. Its 100W input is not a 100W host-output promise. The A8388 support specification separately lists the 85W ceiling. Anker’s port maxima do not establish a simultaneous per-peripheral charging allocation; no such guarantee is made here.

CalDigit lists up to 100W input and up to 90W host pass-through, with power adjusted according to the supply and connected USB devices. Its charging-capability table, dated November 20, 2020 and checked October 14, 2026, gives these examples:

Supply in CalDigit’s tableNo USB deviceUSB-A or USB-C attachedBoth USB-A and USB-C attached
Apple 61W50W44W38W
Apple 96W84W78W72W
100W and above90W84W78W

The values are manufacturer guidance, not measurements we reproduced. A supply above 100W does not raise SOHO’s documented input or host limit. CalDigit excludes chargers below 18W, and a host without supported PD charging cannot be charged merely by connecting the dock.

For either product, compare the laptop’s real required input with the dock’s conditional output. Keep the original laptop power arrangement if the dock cannot meet the workload, following the laptop manufacturer’s instructions. Do not assume two power inputs safely add together.

Compatibility, budget and drawbacks

NeedDocumented candidate to investigateCosts and drawback; current totals unknown
Ethernet, audio and several USB-A devicesA8388Add the required PD supply/cable; two USB-A ports are only 480Mbps
UHS-II camera cards and a replaceable host cableSOHOAdd any needed PD supply or separate Ethernet/audio adapter
Two independent Mac desktopsNeither selected arrangement establishes thisVerify another exact host/dock architecture before purchase
High-power laptop workloadCheck conditional host output before selecting eitherA nominal 100W input is insufficient evidence of required host power
Existing working dockKeep it if it meets the documented setupA new port count alone may not justify another purchase

No current delivered prices, availability or value ranking are established. Our compact USB-C hub guide covers the smaller carry-kit decision, and the USB-C cable guide separates cable charging, data and video requirements. Select the complete host, display and power chain before ordering a dock.

SOHO tablet storage needs a power plan before a faster drive

For an iPad-based photo or file kit, the relevant SOHO question is whether the USB storage path has enough power, not only whether the dock has the right sockets. CalDigit’s SOHO user guide, checked October 29, 2026, separates laptop operation from the tablet case. Its I/O and charging table marks the USB-A and USB-C data ports unavailable in the bus-powered tablet column, with a note that some drives may demand more power than that arrangement provides. The card-reader entries are separately marked available. Do not flatten that table into either “nothing works” or “all ports work” on tablet power.

Intended SOHO jobDocumented power or connection checkBuying consequence
External drive with iPad Pro or Windows USB-C tabletConnect a suitable Type-C charger to SOHO before connecting external storageBudget the charger and charging cable, not just the dock
Read SD or microSD on tablet powerManual lists the readers separately from the USB data portsA card workflow and a bus-powered SSD workflow are different requirements
Use another host cableManual specifies a 10Gb/s, 5A third-party cableA cable sold primarily for charging is insufficient evidence
Change power while copyingManual warns that plugging or unplugging the charger during transfers may disconnect storage and lose dataKeep the chosen power arrangement stable during the transfer

The same manual excludes PD chargers below 18W. Meeting that threshold is not a promise that every drive and host combination will work, or that the tablet receives its desired charging rate. The earlier conditional host-power table still applies. Do not confuse the PD input with the data port when assembling the kit.

Our purchase recommendation is to sketch the actual chain: tablet, SOHO host connection, suitable PD input and storage device. Add each cable, supply and any card to the packing list. If the intended task only reads camera cards, compare that simpler workflow first. If it needs an external SSD, resolve the extra power requirement before paying for a faster or larger drive. Storage speed cannot correct an inadequately powered connection.

Budget and drawback: complete charger, cable and drive totals remain unknown. Reusing an appropriate owned supply may avoid another purchase, but its label and the exact manual requirements need checking. DCL has not transferred files through this setup, measured power or tested disconnection recovery. Keep another verified copy of important files and rehearse the chosen workflow with disposable samples. This section adds tablet-storage planning to the existing dock comparison; it adds no universal iPad or A8388 compatibility promise.

Documentation-based schematic: Choose the transfer job. Card readers differ from USB drives; Connect the documented power chain. Tablet storage may need separate PD input; Keep power stable while copying. No DCL transfer or recovery test. No hands-on test.
Original DCL decision schematic, AI-assisted; not a named-product photograph or hands-on test. Apply the exact-model limits in this section.

SOHO: peripheral power is a separate purchase check from laptop charging

Research checked November 3, 2026. Before selecting SOHO for a powered peripheral, compare that device’s requirement with the downstream port, separately from the laptop’s charging requirement. The manufacturer manual, printed page 12 Interface Summary, labels the USB-C data port 1.5A (7.5W) and USB-A data port 1.3A (6.5W). Those are peripheral-port labels. The larger PD-input and host-charging numbers elsewhere in this guide must not replace them in a peripheral compatibility check.

Connection in the planned kitDocumented boundary to compareWhat remains to establish
USB-C data peripheralManual labels 1.5A / 7.5WDevice requirement and complete host/power arrangement
USB-A data peripheralManual labels 1.3A / 6.5WWhether that exact peripheral works within the documented supply
Laptop chargingUse the conditional host-output table aboveIt does not describe power available from a peripheral socket
Both USB data ports occupiedIndividual port labels plus the actual power arrangementNo measured simultaneous output or universal device guarantee is supplied here

This changes the buying question when an accessory is expected to obtain both data and power through one lead. Write down that accessory’s documented power requirement before counting SOHO as its supply. A 100W input label does not establish a 100W downstream accessory port. If the accessory needs a different supply arrangement, resolve that with its maker rather than assuming a higher-wattage wall charger raises these port specifications.

The earlier tablet-storage section explains why a separate supply can matter for a drive. These downstream ratings add another check after that arrangement has been planned; meeting a nominal rating is not a promise about every drive’s startup or sustained demand. Keep the existing USB-C data/video and charging-input role restrictions as separate requirements. DCL has not measured either downstream port or tested a particular powered accessory.

Selection and budget: retain SOHO when the documented host, data and power arrangement suits the actual equipment. Compare another dock or a peripheral’s supported separate-power option when a requirement falls outside that evidence. Dock, cable, supply and replacement-peripheral totals are unknown. We make no fast-charge, negotiated USB-PD profile or simultaneous full-output claim for these data sockets. A complete connection and power inventory is more useful than paying for a larger input number alone.

SOHO: check peripheral power separately: USB-C DATA: 1.5A / 7.5W label; Check peripheral requirement; USB-A DATA: 1.3A / 6.5W label; Not laptop charging power; COMPLETE KIT: Host and supply matter; No simultaneous test claim
Original DCL schematic, AI-assisted. A documentation-based decision map, not a product photograph or hands-on result.
Research basis

Sources and limits

This guide compares published specifications and source documentation. Daily Carry Lab has not performed hands-on tests of the products in this guide. Consult the dated sources and verify the exact model and current terms before buying.
